OR-CR-253

Description

Passive infrared sensor For indoor usage Collaborates with LED lighting Regulation: lighting time (TIME), sensitivity of the light intensity (LUX) and range of motion detection (SENS).

General information:
Max. load: 2000
Max. load of the LED light source: 500 W
Degree of protection (IP): 20
Relay output: Yes
Nominal voltage: 230V~, 50Hz
Presence detector: Yes
Colour: white
Installation: surface mounting
Dimensions of the sensor - width (mm): Ø120 mm
Dimensions of the sensor - height (mm): Ø120 mm
Dimensions of the sensor - depth (mm): 51.8 mm
Detection angle: 360°
Type of sensor: Infrared
Detection range: Ø3-20 m
Adjustable daylight sensor (LUX): Yes
Daylight sensor adjustment range (LUX): <3—2000lux
Adjustable time setting (TIME): Yes
Lighting time adjustment range (TIME): min: 10 sek. ± 3 sek.; max: 30 min. ± 2 min.
Adjustment of motion detection range (SENS): Yes

Files to download

File category File language File type File update date
Product data sheetPLpdf2024-07-17 10:12:25Download
Product data sheetENpdf2024-07-17 10:20:30Download
User manualPL, EN, DE, FR, RUpdf2024-03-14 10:39:51Download
User manualMEpdf2024-03-14 10:39:51Download
