OR-CR-235

Description

Passive infrared sensor For indoor usage Collaborates with LED lighting Regulation: lighting time (TIME) and the sensitivity of the light intensity (LUX) Greater accuracy (detection of even minor movements) Installation in suspended ceilings.

General information:
Max. load: 800
Max. load of the LED light source: 200 W
Degree of protection (IP): 20
Relay output: Yes
Nominal voltage: 230V~, 50Hz
Presence detector: Yes
Colour: white
Installation: flush mounting
Dimensions of the sensor - width (mm): Ø50 mm
Dimensions of the sensor - height (mm): Ø50 mm
Dimensions of the sensor - depth (mm): 66.5 mm
Detection angle: 360°
Dimensions of the mounting hole: Ø40 mm
Type of sensor: Infrared
Detection range: Ø6m m
Adjustable daylight sensor (LUX): Yes
Daylight sensor adjustment range (LUX): <3—2000lux
Adjustable time setting (TIME): Yes
Lighting time adjustment range (TIME): min.: 10 sek. ± 3 sek., max.: 15min.±2min
Adjustment of motion detection range (SENS): No
