OR-EZ-4010

Description

Asymmetric, cooperates also with double doors It can work with the doorphones and video doorphones installation at the front of single- and multi-family doors Made from Alloy Zamak, which is extremely durable and resistant to corrosion It can be mounted on the outside of the standard faceplate Equipped with a latch lock function - the lever lock movement allows the door to be opened permanently without the use of an electric pulse.

General information:
Power consumption during operation: 800mA 12V AC
Direction of opening: right
Latch adjustment: No
Nominal voltage: 8-14V AC/DC
Mechanical unlocking: Yes
Dimensions - depth: 20.7 mm
Dimensions - width: 20,7 mm
Dimensions - height: 90 mm
Other features: Mini size
Memory: No

Files to download

File category File language File type File update date
Product data sheetPLpdf2024-07-17 10:12:53Download
Product data sheetENpdf2024-07-17 10:20:51Download
