Hermetic cable connectors
New
MICRO cable connector, with a simple shape and very small dimensions. High degree of tightness IP68 protects against external factors, and the innovative O-Ring seal does not expose the seal to damaging external, chemical and mechanical conditions. The material used for the production of the connector is resistant to UV rays and is suitable for outdoor use. Its rigid, compact form and innovative sealing enable installation in the ground. The contacts are made of brass, additionally protected against oxidation with a layer of nickel. The cable gland is equipped with a thick gasket that tightly seals all inserted wires. The product is perfect for outdoor low-voltage lighting installations (with 2 wires + and -). The set includes two pieces.
| General information: | |
|---|---|
| Connector type: | MICRO straight |
| Wire cross-section: | 1,5 mm² |
| Number of wires: | 2 |
| Power supply: | 450V |
| Current: | 16 A |
| Cable gauge: | 2-6,5 mm |
| Degree of protection (IP): | 68 |
| Contacts material: | nickel-plated brass |
| Flame-resistant casing: | yes |
| UV radiation resistance: | Yes |
| Case flammability standard UL94: | V1 |
| Dimensions - length (mm): | 57 mm |
| Type of connection: | screw clamp |
| Underground installation: | Yes |
| Material housing: | PA6 |
