Switch modules
New
| General information: | |
|---|---|
| Function: | Mechaniczna |
| Mounting method: | Montaż podtynkowy, Szyna DIN |
| Width in number of modular spacings: | 3.1 |
| Built-in depth [mm]: | 23 |
| Number of contacts as normally open contact: | 2 |
| Control voltage 1 [V]: | 100-240 |
| Type of control voltage 1: | AC |
| Frequency control voltage 1 [Hz]: | 50/60 |
| Rated current [A]: | 10 |
| Supply voltage [V]: | 100-240 |
| Voltage type (supply voltage): | AC |
| Max. incandescent lamp load [W]: | 2300 |
| Max. switching current (cos phi = 0.6) for LED [A]: | 575 |
| Life time: | 100000 |
| Local control: | Tak |
| Tuya: | Tak |
| Bluetooth: | Tak |
| Wi-Fi: | Tak |
| Operating system: | IOS/Android |
| Wi-Fi Standard: | IEEE 802.11 b/g/n, 2.4GHz |
| Wi-Fi power [W]: | ≤0,2W |
| Standard Bluetooth: | Bluetooth 3.0 |
| Operating Temperature [°C]: | -20 - 70 |
| Height [mm]: | 48 |
| Width [mm]: | 55 |
| Depth [mm]: | 23 |
